Lightweight High Definition P5 Outdoor Full Color Led Display
Boards , LED Video Screen
Product features
- Lightweight. Convenient in transporting and installing & saving
labor cost, suitable for flow shows.
- Nice appearance and simple structures.
- Jointed correctly, being installed & dismounted by one person
without tool.
- Humanized operating interface with breakdown indicator lights, easy
to maintain.
- High debugging brightness and no damage to gray scale, achieving
the debugging technology for nice image.
Product details
| Resolution/mm | 5 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 40000/m² |
| Module resolution | 32x32 |
| Module size/mm | 160x160 |
| View distance | 3-150m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | 7000 cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | 1/8 |
| Frame rate | 60Hz |
| Refresh frequency | >3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >10000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 100000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Maximum power:/㎡ | <700W |
| Average power:/㎡ | <500W |
| Self-check technology | LED spot self-check, communications check, power check, temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature
protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
Our Services
- Reply your enquiry in 24 working hours.
- Experienced staffes answer all your questiones in fluent English.
- Customized desigh is avialiable OEM&ODM are welcomed.
- Exclusive and unique solution can be provided to our customer by
our well-trained and professional engineers and staffs.
- Special discount and protection of sales area provided to our
distributor.
Excellent after-sale service
- Warranty will be valid for 12 months against manufacturing defect.
- The warranty shall not apply to the following circumstances:
1) Damage caused by undue ware& tear, misuse, improper installation
or operation, neglect, accidents.
2) Damage caused by natural disasters, flood fire, lightning or
pollution.
3) If item was opened, any parts removed or repaired by any
unauthorized person.
Why choose us
With more than 9 years experience in led display
producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products
continuous quality.
With large scale production capacity and professional production
technology,our company have built
effective modular production.We always stick to promote the
technical innovation and reduce cost to
benefit customers.
Once we promise the delivery date,we will try our best to fulfill
it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the
products.
Pre-sales:Your purchasing requirements will be highly valued and
we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly
perfect our products.
FAQ
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection
before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-10 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 9 years.Mass and
professional production ensure
our led display’s competitiveness.
Packaging and shipping
A. Flight case Packing
1) 150KG Per flight case
2) 3 cabinets in one case
3) Flight case size: 1010mm*560mm*1175mm=39inch*22inch*46inch
B. Plywood case
1) 180KG per plywood case
2) 3 cabinets in one case
3) Plywood case size: 1120mm*585mm*930mm= 44inch*23inch*36inch
C.customized packing is acceptable
