    P4 P5 P6 P8 P10 P16 Full Color Outdoor Led Video Wall HD Great Weatherproof

    Ask Lasest Price
    Brand Name : Kailite
    Model Number : P4 P5 P6 P8 P10 P16
    Certification : CE,FCC,ROHS ISO9001
    Price : Negotiation
    Payment Terms : T/T, D/A, D/P, L/C, Western Union, MoneyGram
    Supply Ability : 8000sqm per month
    Delivery Time : 5--20 working days
    • Product Details
    • Company Profile

    P4 P5 P6 P8 P10 P16 Full Color Outdoor Led Video Wall HD Great Weatherproof

    P4 P5 P6 P8 P10 P16 Full Color Outdoor Led Video Wall HD Great Weatherproof


    Product Features:


    • Full color outdoor advertising LED Display Screen displays perfect vivis image, video, animation, flash, txt.
    • Super brightness and waterproof is the best product for outdoor daily and night use.
    • Wireless control and energy saving is the best choice for advertising billboard permanently.
    • LED Display Cabinet design for easy install and dismantle.

    Product Technical Specification:


    Pitch/mmP4P5P6P8P10P16
    Module size/mm128x128160x160192x96256x128160x160256x256
    Density of pixel/(dots/m2)6250040,00027,77715,62510,0003,906
    Pixel compositionSMD 3 in 1SMD 3 in 1SMD 3 in 1SMD 3 in 1SMD 3 in 11R1G1B
    Led encapsulationSMD1921SMD2727SMD3535SMD3535DIP346/SMD3535DIP346
    Optimum viewing distance4-16m≥5m≥6m≥8m≥10m≥16m
    View angle / °140 H,120 V140 H,120 V140 H,120 V140H,120V110 H,60 V110 H,60 V
    Average power consumption/W/M21,0001,000900500450350
    Size of cabinet/mm1024X1024960X960960X9601024X1024960X9601024X1024
    Driving method1/16 scan constant current1/8 scan constant current1/8 scan constant current1/4 scan constant current1/2 scan constant currentStatic constant current
    Refresh rate Hz/S≥2400≥2400≥2400≥2400≥2400≥2400
    Luminance of white balance≥6000 nits≥6000 nits≥6000 nits≥6000 nits≥6000 nits≥6000 nits
    Operation of Environmental Temperature/℃(-30℃~+50℃)
    IP ratingIP65
    Working voltage110-220 VAC/+/- 10%
    Grey scale/colordisplaying colors≥16.7M(synchronized)
    Brightness adjustment4096 levels of each color(manually),100 levels of each color(automatically)
    Input signalRF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
    Control systemLinsn / Nova(sending card,receiving cards and Hubs)
    Average of non-failure life>50,000h
    Life span>100,000h
    Functionless dot rate<0.0001

    Our Services

    1) Reply your inquiry in 24*7 working hours.
    2) Professional staffs answer all your question in fluent English.
    3) Personalized solution will be provided to you by our veteran and professional engineers and staffs.
    4) Warranty: Two-Five Years, a little investment for longer warranty time.
    5) Special discount and protection of sales area provided to our distributor.

    FAQ

    1. How can i place an order?


    Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with Skype/email /phone, in case of any delays.

    2. What kind of display we provide?


    We have indoor/outdoor/led curtain/mobile LED /rental LED display /LED stage/LED Dance Floor/Irregular LED display for you choose.

    3. What about the lead time for order?


    Always: 3-20 days, as your order quantity, sometimes we have stock, can delivery within 5 days

    4.How about the warranty ?


    We have two years warranty.
