rgb video walls high contrast P3.91 SMD2121 commerical rental usage
with control system
Product advantage:
1. LEDs: we select super led tips with high brightness, broad
viewing angle(H140degree, V140degree), all the LEDs are ageing for
72 hours before assembly,
2. Modules: We use 1R1G1B pixel configuration to realise high
brightness.Modules would be aging for 72 hours, after assembly into
a screen, still aging 72 hours. so the final LEDs are aging at
least for 216 hours, up to 9 days.
3. Cabinets: Aluminum/ Iron
4. Screen: use state-of-the-art LED drive IC-MBI5026/MBI5124,
brightness can up to 8000cd/m2, live color video and vivid image
with 256 grey level.
For outdoor led displays, all of them are IP 65 and designed to
withstand harsh environmental conditions, such as sun glare, heat,
cold, and humidity. You can see more details in the quotation.
5.Packing: Anti-shaking wooden case, which is lighter than normal
wooden case but more protective to the goods. Flight case with
wheel which is more convenient .
6. Spare parts for free: Our screen's scotoma rate is below 0.0002,
but to prevent accidental, we provide some free spare parts
according to the size of screen.
7. Warranty for 24 months: During the guarantee period, we will
send new lights with new order for small quantity. For defective
batch products, we will repair them and resend them to you or we
can discuss the solution according to situations.
8. Technology support: we have full hardware and software files
available for all you need, we are here to working for you.
Specification:
| Items | Parameter |
| Pixel Pitch | P3.91mm | P4.81mm |
| Module Resolution(W*H) | 128*128 | 104*104 |
| Pixel Configuration | 1R1G1B | 1R1G1B |
| Optimal Viewing Distance | 4-28m | 5-30m |
| Pixel Density(Pixel /m2) | 65536 | 43264 |
| Driving Method | 1/16 Scan | 1/13 Scan |
| View angle / ° | 140H,120V | 140H,120V |
| Module size(mm) | 250x250 | 250x250 |
| Cabinet size(mm) | 500x500/500x1000 | 500x500 |
| Luminance of white balance | ≥1300 CD/m^2 | ≥1200 CD/m^2 |
| LED Encapsulation | SMD2121 | SMD2727 |
| Weight of cabinet/kg | 10 | 9 |
| Working Voltage | AC 220V/110V±10% |
| Operating Temperature | below 30 to above 50 |
| Grey scale/color | displaying colors≥16.7M(synchronized) |
| Brightness adjustment | 256 levels of each color(manually), 100 levels of each color(automatically) |
| Input signal | RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc |
| Control system | linsn(sending card,receiving cards and Hubs) |
| Average of non-failure life | >50,00h |
| Life span | >100,000h |
| Defect dot rate | <0.0001 |
Famous Brands Raw Material Selection
1) LED: well-known international brand,with wide viewing angle
,little attenuation ,good heat dissipation, and vivid colors.
2) Driving IC: famous brands such as, Taiwan MBI, Japanese Toshiba,
avoidable the defective
phenomena, such as dark bright, virtual light and so on.
3) Power supply: industrial-strength brand.The power maximum power
resere of 20% the space , the range of voltage fluctuation is less
5%, high stability.
4) Connector: Aerial grade brands ensure the stable transmission of
power and signal.
5) PCB Board: adopt 4-layer design.
6) Easy installation:100 pieces of cabinets' installation can be
finished in one hour by one person.
The replacement of any cabinet can be done within 50 seconds.
Services
1) Reply your inquiry in 24 working hours.
2) Experienced staffs answer all your query in fluent
English,Spanish,French,German etc
3) Customized design is available,OEM & ODM are welcomed.
4) Exclusive and unique solution can be provided to our customer by
our well-trained and professional engineers and staffs.
5) Special discount and protection of sales area provided to our
distributor.
6) Warmly welcome your visit in our company if available.
7) Warranty: 24 months
Packaging & Shipping
6 panels or 8 panels in 1 flight case
